Industrial PC
DIN Rail Mount Computers
Wide temperature fanless industrial computer with Intel X6413E processor and 8 LAN ports

Wide temperature fanless industrial computer with Intel X6413E processor and 8 LAN ports

Model NO. IFW64802

Customization OEM accepted

Datasheet (PDF) [4] Images

Wide Temperature Industrial Computer

Industrial Computer With 8 LAN Ports

Fanless Industrial Computer

Industrial Computer With Onboard Intel X6413E Processor

Features

Industrial embedded box computer for industries network application
Onboard Intel® Celeron quad-core X6413E processor, 1.91GHz, 2MB cache
One 260pin 3200MHz DDR4 SO-DIMM RAM, max 32GB RAM
4x 2.5 Gigabit RJ45 + 4x 1G RJ45 Ethernet ports, supports three channels LAN BYPASS
One RJ-45 Console interface, one RS-232 Console interface
Two USB3.0, mSATA storage
Two 12~48V DC wide voltage inputs, with alarm for power failure
Multi-function LED indicators
Fanless thermally conductive aluminum extrusion to support wide temperature working
Support DIN-RAIL rail type mount
Widely used in industrial-application environments

Specifications

Motherboard

Storage

Ethernet

LAN Ports 2.5G Four 2.5G RJ45 network interfaces, Intel® Ethernet Controller I225-V
LAN Ports 1G Four 1G ethernet ports, RJ45 interface, Intel i350 ethernet Controller
BYPASS Support three channels Gen3.0 LAN BYPASS
Indicator With LAN link, active, speed LED, built-in BYPASS status LED

External I/O

Power supply

Environmental

Mechanical

Ordering informations

IFW64802 Industrial computer, network application appliance, Din rail mount, Aluminum extrusion chassis, Intel X6413E CPU, 4 x 2.5G RJ45, 4x 1G RJ45, three lan bypass, 60W Power adapter
