17 inch Industrial all in one PC with touch screen

Country of Origin: China
Customization OEM accepted

Datasheet (PDF) [1] Images

Industrial All In One PC

Features

17" SXGA TFT LCD Panel support 1280 x 1024 pixels &touch screen
Intel Celeron J1900 Quad Core 2.0G CPU
Supports Windows XP Professional and WinXPe, Win7, Win8, Win10, Linux
2*COM,1*HDMI,1*VGA,4*USB,1*GLAN,1*AUDIO,1*MIC
1* Mini PCIe slot and wifi optional
Panel ( Flush ) mount with clips
Standard VESA 75mm support stand , wall mount and swing arm

Specifications

System

Processor Intel Celeron J1900
Chipset ICH8M
Memory DDR3 2G RAM(Max 8G)
Storage SSD 32G(HDD optional)
Ethernet 1 x 100/1000 LAN ports
Audio 1x line out
USB Port 4 x USB 2.0
Serial Port 2 x RS-232
Power switch 1 x power switch
Expansive Slot 1 x Mini PCIe
Power supply DC12V(Optional 9-36V)
Construction Front aluminum bezel and steel chassis

LCD display

Display Type 17 XGA TFT LCD
Resolution 1280 x 1024
Max.color 16.2M
Luminance 300 cd/m2
View Angle 150°(H) , 135°(V)
Pixel Pitch 0.297 x 0.297 mm
Contrast Ratio 700:1
Response Time 8 ms
LCD MTBF 50, 000hrs

Available Options

Touch screen Resistive type touch screen
Wireless LAN Meet IEEE802.11b/g standard(WiFI)
DC Power Input Wide Range 9~36v DC input

Power supply

Input 100~240VAC , 50/60Hz
Output DC 12V-In , external ac adapter with lockable connector

Environmental

Operate temperature 32 °F~125 °F (0 °C to 50°C)
Storage temperature -4 °F~140 °F (-20 °C to 60 °C)
Storage humidity 10% to 90% non-condensing
Anti-Vibration 17HZ-500 HZ 1G PTP
Anti-Shock 1G / peak( 11m sec)
Approvals CE/ROHS

Packing info

Dimensions (WxHxD) 432X346X80.6 mm
Weight Net: 8kg , Gross:11 kg

Ordering informations

IPC-0217J 17 inches industrial LCD All in one touch screen PC, withIntel J1900 Processor, 2G RAM,32GSSD,2*COM,1*HDMI,1*VGA,4*USB,1*GLAN,1*AUDIO,1*MIC , Resistive Touch Screen
