19 inch industrial panel pc with 1 LPT 6 COM

Model NO. IPC-19A

Customization OEM accepted

Datasheet (PDF) Dimensions Drawing [4] Images

Industrial Panel Pc With 1 LPT

Panel Pc With 1 LPT

19 Inch Industrial Panel Pc

19 Inch Industrial Computer

Features

19" SXGA TFT LCD Panel support 1280x1024 pixels
6mm Aluminum front bezel with resistive touch screen
Intel Celeron J1900 Quad Core 2.0G CPU
Supports Win7/Win8/Win10, Linux
6xCOM(5*S232,1*RS422/RS485) , 1x LPT, 2x PS/2, 1xVGA, 4xUSB2.0, 2xLAN, 1x Audio, MIC
1* Mini PCIe slot for wifi optional
Standard DC 12V input (optional Wide range DC 9-36V input)
Panel ( Flush ) mount with clips
Standard VESA 75/100mm support stand , wall mount and swing arm

Specifications

System

Processor Intel Celeron J1900
Chipset Intel Bay trail SOC
Memory DDR3 4G RAM (Max 8G)
Storage 2.5" HDD/ SSD ( Size optional)
Graphic Intel HD chipset
Ethernet 2 x 100/1000 LAN ports
Video 1 x VGA
Audio 1x Mic-in and 1x Line-out
USB Port 4 x USB 2.0
Serial Port 6*COM(5* RS232,1*RS422/RS485)
Parallel ports(LPT) 1 x SPP/EPP/ECP port
Keyboard /Mouse 2xPS/2
Power switch 1 x power switch
Expansive Slot 1 x Mini PCIe
Power supply DC12V input (Optional 8-30V), 100~240V AC , 50/60Hz, external ac adapter
Construction Front aluminum bezel(6 mm) and steel chassis

LCD display

Touchscreen

Environmental

Power supply

Packing info

Ordering informations

IPC-19A 19" industrial panel PC, with Intel J1900 Processor, 4G RAM(Optional 8G), 2.5" SSD/HDD (Size optional), 6*COM(5* RS232,1*RS422/RS485), 1x LPT, 2x ps/2, 1xVGA, 4xUSB,, 2xLAN, 1x Audio, MIC, Resistive Touch Screen,12v power adapter
IPC-19AL IPC-19A + Mini-PCIE wireless Lan card with antenna
