15 inches Industrial LCD monitor with touch panel

Country of Origin: China
Customization OEM accepted

Datasheet (PDF) Dimensions Drawing [3] Images

Industrial Panel Monitor

Touch Screen Industrial Monitor With HDMI

Touch Panel Monitor

Features

15" XGA TFT LCD Panel support 1024 x 768 pixels,250 cd/m2 brightness
6mm Aluminum bezel panel with touch screen/strengthen glass
Rugged construction and modularized design
VGA + HDMI or DVI + Audio Input signal(AV Optional)
2 x stereo speakers for industrial automation system voice output
OSD control keys to optimize the display
AC 100-240V wide range external ac adapter
NEMA4 / IP 65 compliant front panel
Panel ( Flush ) mount with bracket or standard VESA hole (100x100mm) supports desktop stand / wall mount/ swing arm mount
Application for HMI, Kiosk, Automation, M2M, heavy Manufacturing Equipment(CNC, machine tool etc.)

Specifications

Display

Display Type 15" XGA TFT LCD
Resolution 1024 x 768
Max.color 16.2M
Luminance 250 cd/m2
View Angle 178°(H) , 160°(V)
Pixel Pitch 0.297 x 0.297 mm
Contrast Ratio 700:1
Response Time 5 ms
LCD MTBF 50,000hrs

Input Signals

RGB Signal D-SUB 15P Connector (female)
DC input DC Jack (2.1mm)
Video Input (option) RCA Connector
S-Video signal (option) S-Video (SVHS)plug
DVI-D Signal DVI-D input 24pin connector (female)
Touch screen RS232 (option) D-SUB 9p connector (female)
Touch screen USB (option) USB-A type connector (female)

Available Options

Touch screen Resistive Type with USB and RS232 controller
DC Power Input Wide Range 8~30v DC input
AV input Composite Video/Audio, S-Video Input

Power supply

Standard 100~240VAC,50/60Hz, DC12V@5A / 60W ,external ac adapter
DC-DC Power DC 8 ~ 30v input power module(optional)

Environmental

Construction Heavy duty steel and aluminum front panel
Operate temperature 0 °C to 50 °C
Storage temperature -20 °C to 60 °C
Storage humidity 10% to 90% non-condensing
Anti-Vibration 17HZ-500 HZ 1G PTP
Anti-Shock 1G / peak( 11m sec)

Packing info

Dimensions (WxHxD) 375 x 300 x 42 mm
Weight Net: 6.0kg , Gross: 8.0 kg

Ordering informations

IDM-15 15" Industrial Panel Mount Monitor with VGA + HDMI/ DVI + Audio Input
IDM-15TC 15" Industrial LCD Monitor with VGA + HDMI/ DVI + Audio Input, with touch screen and RS232 controller
IDM-15TU 15" LCD Industrial Panel Mount Monitor with VGA + DVI/ HDMI + Audio Input, with touch screen and USB controller
IDM-15A 15" Industrial Monitor with VGA + DVI/ HDMI + Audio + S-Video + Video Input or BNC input
IDM-15ATC 15" Industrial Panel Mount Monitor with VGA + HDMI/ DVI + Audio + S-Video + Video Input or BNC input, with touch screen and RS232 controller
IDM-15ATU 15" LCD Industrial Monitor with VGA + DVI/ HDMI + Audio + S-Video + Video Input or BNC input, with touch screen and USB controller
